Growatt – MOD 10KTL3-X
€1,200.00
Growatt MOD 10KTL3-X is a high-efficiency, 3-phase, on-grid solar inverter with 10 kW output, dual MPPTs, and 98.6% peak efficiency. It supports up to 15 kW of PV input, has IP66 protection for outdoor use, smart monitoring via Wi-Fi, and advanced safety features like AFCI and surge protection. Battery-ready versions (XH) are compatible with Growatt storage systems.
Jinko Solar – Tiger Neo N-Type 580W
Price: €429.00
The Jinko Solar Tiger Neo N-Type 580W is a high-performance monocrystalline solar panel featuring advanced N-type cell technology, 22.45% efficiency, and excellent reliability for long-term use. With low degradation rates, robust construction, and SMBB (Smart Multi-Busbar) design, it delivers consistent energy output even in diverse and harsh climates. Backed by a 12-year product warranty and 30-year performance guarantee, it is a top choice for both residential and commercial solar installations.
⚡ Key Specifications
Electrical (DC) Characteristics
- Maximum power (Pmax): 580 W
- Module efficiency: up to 22.45%
- Maximum power voltage (Vmp): ~42 V
- Maximum power current (Imp): ~13.8 A
- Open-circuit voltage (Voc): ~50 V
- Short-circuit current (Isc): ~14.6 A
- Maximum system voltage: 1500 V DC (IEC/UL)
- Power tolerance: 0 ~ +3%
Cell & Module Design
- Cell type: N-Type monocrystalline, 182 mm wafer size
- Number of cells: 144 (half-cut configuration)
- Multi-busbar (SMBB) design for improved efficiency
- Anti-PID (Potential-Induced Degradation) protection
- Bifacial capability: up to 30% rear-side power gain
Durability & Protection
- Glass: High-transmittance, anti-reflective tempered glass
- Frame: Anodized aluminum alloy, corrosion-resistant
- Junction box: IP68 rated, 3 bypass diodes
- Cables: UV-resistant solar cable, 4 mm², length 1.2 m
- Connector type: MC4 compatible
- Mechanical load capacity: 5400 Pa (snow), 2400 Pa (wind)
Mechanical & Environmental
- Dimensions: 2278 × 1134 × 30 mm (L×W×H)
- Weight: ~29 kg
- Operating temperature: –40 °C to +85 °C
- Fire rating: Class C
- Salt mist & ammonia resistant (suitable for coastal/agricultural sites)
Performance & Warranty
- Annual degradation: ≤ 0.4%
- Performance after 30 years: ≥ 87.4% of initial output
- Product warranty: 12 years
- Performance warranty: 30 years
| Color |
Beige ,Black ,Brown |
|---|---|
| Battery Compatibility (for XH / XH BP variants) |
Compatible with Growatt ARK XH batteries (7.68–25.6 kWh) and APX battery system (5–30 kWh) for hybrid/battery-ready setups |
